DESCRIPTION:
A double-acting O-Ring energized seal designed for rotating, oscillating and helically moving pistons, rods and shafts. It is installed in grooves to ISO 7425 and is available in a single-acting version for higher rotating speeds.
OPERATIONAL CONDITIONS:
Pressure (max): 30 Mpa
Temperature: -45 °C to +200 °C
Size Range: 6 mm to 2500 mm
Speed (max): 2 m/s
Basic Material: PTFE/NBR
Filler: Virgin PTFE compounded with Turcon®, mineral fibre and additives
Commercial Description:
Turcon® M12 is used as a primary sealing material and paired with an NBR (N7) elastomer with O-ring energized seals. Turcon® M12 offers low friction, high wear resistance, and costs on par with standard bronze-filled compounds. NBR is used to provide good, general sealing capabilities.
TSS item no. | Product name |
TG4000080-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000100-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000100-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000120-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000140-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000140-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000150-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000150-T40E | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000150-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000150-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000160-T05V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000160-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000160-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000180-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000180-T40E | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000180-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000180-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000200-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000200-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000200-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000220-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000220-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000220-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000250-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000250-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000250-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000280-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000280-T10V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000280-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000280-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000280-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000300-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000300-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000300-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000300-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000320-T05N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000320-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000320-T40E | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000320-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000320-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000350-T10J3 | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000350-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4000350-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100400-T01N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100400-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100400-T10V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100400-T29N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100400-T40E | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100400-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100400-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100400-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100400-T46V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100420-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100420-T10V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100420-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100420-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100450-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100450-T10V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100450-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100450-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100450-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100480-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100480-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100500-T01N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100500-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100500-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100500-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100500-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100500-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100520-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100520-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100550-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100550-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100550-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100600-T01N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100600-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100600-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100600-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100600-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100630-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100630-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100630-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100630-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100650-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100650-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100650-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100650-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100700-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100700-T10V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100700-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100700-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100700-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100700-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100750-T01N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100750-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100750-T10V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100750-T40E | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100750-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4100750-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200800-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200800-T29N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200800-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200800-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200800-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200800-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200850-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200850-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200900-T10E | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200900-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200900-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200900-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200900-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200900-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200950-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200950-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4200950-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201000-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201000-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201000-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201000-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201000-T46V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201000-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201050-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201050-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201100-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201100-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201150-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201150-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201150-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201200-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201200-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201200-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201200-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201200-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201200-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201250-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201250-T10V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201250-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201250-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201250-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201250-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201250-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201300-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201300-T29N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201300-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201300-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4201300-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301350-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301350-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301350-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301350-Z80V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301400-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301400-T10V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301400-T29V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301400-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301400-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301400-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301500-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301500-T29V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301500-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301500-Z80N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301600-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301600-T29V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301600-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301600-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301700-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301700-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301700-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301700-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301800-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301800-T31V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301800-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301900-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301900-T40E | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301900-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4301900-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302000-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302000-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302000-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302000-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302000-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302100-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302100-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302100-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302100-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302200-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302200-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302200-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302300-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302300-T29N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302300-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302300-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302400-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302400-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302400-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302500-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302500-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302500-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302800-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302800-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4302800-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4303000-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4303000-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4303000-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4303200-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4303200-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4303200-T42N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4303200-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4403500-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4403500-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4403500-T40V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4404000-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4404000-T10V | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4404200-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4404200-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4404500-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4404500-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4404800-T40N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4405000-T10N | TSS Turcon Roto Glydring with O-Ring (as Set) |
TG4406000-T46N | TSS Turcon Roto Glydring with O-Ring (as Set) |
Carbosteam 6550
Carbosteam
S 6555
G-Spezial 6560
G-Spezial S 6565
Special
Carbon 6540
Uniflex 6588
Unimix Black 7106
Unimix White 7105
Click here to send a message or inquiry
GermanBase GmbH
Am Halberg 10
D-66121 Saarbruecken
Germany
e-mail: info@germanbase.de
Fax: +49 681 950910-9
